Heavy Industrial SPM
Model: NCT-SPM-25
Comprehensive Machine Overview
Engineered for high-throughput production in demanding fabrication environments, the Bolt Threading Machine by National Cutting Tools is built for <p>The Bolt Threading Machine by National Cutting Tools is an industrial machine tool engineered for precision external thread cutting on solid steel bolts, anchor studs, threaded rods, and fastener blanks. Producing bolts on general-purpose lathe machines requires multiple tool passes and skilled turners; this dedicated bolt threader cuts finished, full-depth threads in a single pass at production rates up to 100 to 200 bolts per hour.</p>.
<p>Featuring an all-geared headstock driven by an electric motor, the machine uses an adjustable die head fitted with four tangential HSS chasers. The workpiece is clamped in a rigid, self-centering vise and fed toward the rotating die head via a positive lead screw or rack mechanism. When the preset thread length is reached, the automatic trip mechanism opens the die head cleanly, allowing instant carriage retraction without marking the finished thread.</p>
<h3>Key Features</h3>
<ul>
<li><strong>Single-Pass Full Thread Cutting:</strong> Multi-tooth tangential chasers cut completed metric, BSW, UNC, or UNF thread profiles in one continuous forward stroke.</li>
<li><strong>High-Rigidity Headstock:</strong> Heat-treated alloy gears provide high torque at regulated RPM to prevent tool chatter and preserve close pitch tolerances.</li>
<li><strong>Self-Opening Tangential Die Head:</strong> Instantaneous radial opening of cutters at the length stop eliminates thread scuffing and tool damage on reverse.</li>
<li><strong>Heavy Self-Centering Bar Vise:</strong> Hardened V-jaws grip hex, square, and round bars firmly on the spindle centerline to prevent eccentric threads.</li>
<li><strong>High Tool Life per Regrind:</strong> Tangential chaser design allows sharpening simply by grinding the front cutting face, maintaining original tooth pitch for months.</li>
<li><strong>Automatic Flood Coolant:</strong> Continuous coolant stream flushes hot steel swarf and lubricates cutting interfaces, ensuring mirror-smooth thread flanks.</li>
</ul>
<h3>Applications</h3>
<ul>
<li>High-output foundation bolt (L-type, J-type, and straight) threading</li>
<li>Automotive and structural hexagonal bolt and stud manufacturing</li>
<li>Transmission tower and railway track fastener threading</li>
<li>Scaffolding tie rod and threaded anchor pin production</li>
</ul>
<p>Manufactured at the National Cutting Tools plant in Ludhiana, Punjab. Every machine is calibrated for pitch accuracy, lead linearity, and runout before release for domestic delivery or overseas export.</p>
Engineering Data Matrix
| Technical Parameter | Operational Specification / Value |
|---|---|
| Type | Machine |
| Material | Stainless Steel, Or Aluminum |
| Quality | Best Quality |
| Thread Type | Metric, BSW Or UNC |
| Finish | Painted |
| Max Thread Length | 100 Mm – 200 Mm |
| Size Range | M6 – M100 |
| Control Method | PLC Or CNC |
| Motor Power | 1.5 KW To 5.5 KW |
| Phase | Three Phase |
| Motor Type | AC Induction Motor |
| Threading Method | Chasing, Or Cutting Threading |
| Base Shape | Rectangle |
| Tapping Attachment | Available As Optional Attach |
| Application | Industrial Use |
| Cooling System | Automatic Cooling Pump |
| Corrosion Resistance | Yes |
| Lubrication Type | Manual Or Automatic Lubricated |
| Country Of Origin | India |
Bolt Threading Machine Works QA & Export Packaging Protocol
✓ Thread Geometry & Pitch Gauge Verification Protocol
- • Thread Pitch & Gauge Inspection: Sample threads cut or rolled on bar/pipe stock verified with calibrated Go / No-Go thread ring and plug gauges (IS 554 / ISO 7 / IS 16172).
- • Chaser / Roll Die Parallelism: Die head trip mechanism and roll die spacing aligned within 0.02 mm under full cutting and forming torque.
- • All-Geared Headstock Burn-In: 48-hour continuous trial of all spindle speeds and coolant circulation under loaded cutting conditions to ensure thermal stability.
- • Thread Sample Sign-Off: Physical threaded test samples preserved and HD video of threading cycle sent for buyer approval before packing.
Precision Threading Machine Transit Protection
- • Die & Lead Screw Wax Coating: Chasers, thread rolls, vice jaws, and lead screws coated with heavy-viscosity protective rust-preventive petroleum wax.
- • Carriage Mechanical Locks: Workpiece carriage and rack gear secured to prevent movement and shock during sea transit.
- • Cabinet Desiccant Packs: Hermetically sealed silica gel canisters placed inside control enclosures to prevent condensation.
- • ISPM-15 Heat-Treated Crating: Heavy wooden box packaging compliant with international maritime phytosanitary export standards.
International Shipping Destinations & India Supply Network
National Cutting Tools manufactures and configures the Bolt Threading Machine for seamless integration into international fabrication lines and domestic scaffolding manufacturing plants. All machinery is customized for local electrical grids, certified for regional compliance, and dispatched with seaworthy protective packaging.
Primary International Export Destinations
All Export Hubs →Pan-India Fast Freight Dispatch (Ludhiana Works)
India Directory →Full-truckload (FTL) and part-load freight dispatch directly from our central manufacturing works at Focal Point, Ludhiana. Factory engineers provide on-site leveling, tool alignment, and operator training across all major industrial manufacturing clusters:
